製品特徴
製品パラメータ
| Size | Serial No. | Resolution |
Outline
(W*H*D) (mm)
|
A.A
(W*H) (mm)
|
Interface |
TYP Luminance
(cd/m²)
|
Operating Temp.
(℃)
|
| 2.1 QT | AVD-TT21QT-NN-005-S | 480*480 | 56.18*59.71*2.22 | φ53.28 | MIPI | 500 | -20~+70 |
| 2.4 QV | AVD-TT24QV-NN-014-S | 240*320 | 42.72*58.50*2.15 | 36.72*48.96 | SPI/MCU | 400 | -20~+70 |
| 2.4 QT | AVD-TT24QT-NN-001-C | 450*600 | 38.72*51.56*0.78 | 36.72*48.96 | MIPI/MCU/SPI | 800 | -20~+80 |
| 2.8 QV | T028QV0009NNA01‑S | 240*320 | 50.00*69.20*2.30 | 43.20*57.60 | SPI/MCU | 400 | -20~+70 |
| 3.5 QV | T035QV0052NWC01‑S | 320*240 | 76.85*64.00*2.8 | 70.08*52.56 | LVDS | 1000 | -30~+80 |
| 3.5 HV | T035HV0059NWC01‑S | 320*480 | 54.46*82.94*4.15 | 48.96*73.44 | SPI/MCU/RGB | 1000 | -30~+85 |
| 3.5 HV | T035HV0040DNB01‑IS | 320*480 | 54.46*82.94*4.1 | 48.96*73.44 | MIPI | 500 | -30~+85 |
| 3.97 WV | T040WV0016NNB01‑S | 480*800 | 57.70*97.30*2.15 | 51.84*86.40 | MIPI | 500 | -20~+70 |
| 4.0 QT | T040QT0052NNB01‑S | 480*480 | 76.00*78.20*2.26 | 71.856*70.176 | MIPI | 600 | -20~+70 |
| 4.0 QT | T040QT0019DNA01‑I | 480*480 | 74.66*76.54*2.0 | 71.86*70.18 | RGB | 350 | -20~+60 |
| 4.3 WQ | T043WQ0081NNA01‑S | 480*272 | 105.40*67.10*2.85 | 95.04*53.86 | RGB | 250 | -20~+70 |
| 5.0 WV | AVD‑TT50WV‑NW‑196‑S | 800*480 | 120.70*75.80*2.80 | 108.00*64.80 | RGB | 500 | -30~+85 |
| 5.0 FW | T050FW0011DNA01‑IS | 480*854 | 66.40*120.05*2.16 | 61.78*109.91 | RGB | 350 | -20~+70 |
| 7.0 WS | T070WS0143NNB01‑S | 1024*600 | 164.90*100.00*3.45 | 154.21*85.92 | LVDS | 500 | -20~+70 |
| 8.0 WX | T080WX0044NSA01‑S | 800*1280 | 114.66*184.16*2.49 | 107.64*172.22 | MIPI | 350 | 0~+60 |
| 10.1 WS | T101WS0039NNB01‑S | 1024*600 | 235.00*143.00*4.60 | 222.72*125.28 | MIPI | 350 | -20~+70 |
| 10.1 WX | AVD‑TT101WX‑NN‑227‑S | 800*1280 | 143.00*228.60*2.72 | 135.36*216.58 | MIPI | 250 | 0~+50 |
