Product Feature



Shutter LCD is a kind of nematic phase distortion liquid crystal device, which can control and adjust the transmittance of incident light intensity by changing the deflection of liquid crystal through electric field;

Meet European standard EN379 and American standard ANSI z871-2003;

Main specifications: 96*48mm, 103*34mm, 105*66mm, 107*95mm (customizable).


Dual Cell

Optical grade (optical properties, diffusion, uniformity, view angle dependence): 1/1/1/2 & 1/1/1/1

Power on state: 4# color, Power off state: 9~13# color

Opening time: ≥0.15ms

Operating temperature: -10~60°C

Lifetime: 5 years


Single Cell

Power on state -- 3# color, Power off state -- 11# color

Optical grade: 1/1/1/1

Color adjustable: power on state -- 3# color,  power off state -- 8~11# color
